Guide to Matching Your Valen Solar Panels and Pole Mount Brackets

When building an off-grid or remote solar system, choosing the right solar panel mounting bracket is just as important as selecting the right solar panel. Valen’s pole-mount solar panel brackets are engineered for durability, flexibility, and easy installation — making them ideal for applications such as water pumps, communications sites, monitoring equipment, and standalone solar systems across Australia.

Why Choose Valen Solar Panel Brackets?

Valen’s solar panel pole mounts are designed to deliver strength and simplicity in one complete package. Each mount has been tested for Australian conditions and offers:

• Maximum energy efficiency: Adjustable mounting angles help you optimise your solar panel performance for different sun positions and site locations.

• Wind certification: Certified to meet Australian standards, helping reduce risk and liability during installation.

• Flexible sizing options: A streamlined range that covers all your solar panel and pole diameters, simplifying ordering and installation.

• Quick, simple installation: Designed to save time onsite and reduce labour costs.

Whether you’re installing one panel or building a complete off-grid solar system, Valen brackets offer a professional and secure mounting solution that lasts.

Valen Solar Panel Bracket Sizes

Valen stocks three sizes of solar panel brackets, each designed to suit a specific range of panel dimensions and pole diameters.

Size	Code	Pole Size (OD)	Panel Height	Panel Width	Max Panel Weight
SPB VS*	SB60101	37–80 mm	215–357 mm	345–775 mm	9 kg
SPB VM*	SB60102	80–150 mm	540–682 mm	515–1005 mm	14 kg
SPB VL*	SB60103	80–150 mm	540–682 mm	890–1500 mm	14 kg

All Valen solar panel brackets feature four pre-set tilt angles — 15°, 30°, 45°, and 60° — allowing you to adjust for maximum sunlight exposure throughout the year.

Solar Panel and Bracket Compatibility Guide

To make system design easy, the table below matches Valen and Victron solar panels to the correct Valen bracket for fast selection and installation.

SKU	Description	Watts	Length (mm)	Width (mm)	Height (mm)	Compatible Bracket
SP40612	Valen 20W Poly	20	470	345	25	SB60101
SP41012	Victron 20W 12V Poly	20	440	350	25	SB60101
SPV25	Valen 25W Solar Panel	25	530	355	30	SB60101
SP40649	Valen 40W Poly	40	775	350	35	SB60101
SP40686	Valen 50W Poly	50	665	535	35	SB60102
SP41008	Victron 55W 12V Mono	55	545	668	25	SB60102
SP41075	Instapower 60W 24V Mono	60	580	670	35	SB60102
SP40723	Valen 80W Poly	80	775	665	35	SB60102
SP40538	Valen 100W Poly	100	1005	665	35	SB60102
SP41079	Victron 115W 12V Poly	115	1030	668	30	SB60103
SP40575	Valen 160W Poly	160	1480	665	35	SB60103
SP41055	Victron 215W 24V Mono	215	1580	705	35	SB60103
SP40010	Valen 300W Mono	300	1640	990	35	SB60103

Built for Australia’s Harsh Conditions

Every Valen solar panel bracket is made to withstand the demanding environments of remote and regional Australia. From outback monitoring stations to coastal installations, our brackets provide a secure, long-lasting foundation for your solar power system.

Valen’s solar panels and brackets are designed to work together seamlessly — giving you peace of mind that your system will stay strong, efficient, and safe for years to come.

Need Help Choosing?

Not sure which solar panel mounting bracket is right for your project?
Contact the Valen Power team — our specialists can help you match the right panel and pole mount bracket to your application and location.

👉 Get in touch today to discuss your next off-grid solar mounting system.
